A fiber optic patch panel serves as a centralized, passive hardware enclosure that organizes, terminates, and protects fiber optic cables. It provides a static interface between structural trunk cabling and the dynamic patch cords that connect to active networking equipment. Patch panels are rack-mountable onto 19”, 21”and 23” rack systems, and some are designed to be wall-mountable. In physical terms, it is usually a metal enclosure. An optical fiber patch Cable is a jumper wire used to connect from equipment to an optical fiber cabling link, and it is usually used for the connection between an optical transceiver and a terminal box. Facilitates splicing (joining fibers) and.
